Main parameters of J599 III Circular photoelectric Hybrid connector
Product Parameters
| Mechanical Properties | Mechanical Life | 500 mating cycles |
| Shock | 3ms half sine wave, acceleration 2940m/s² | |
| Vibration | 10Hz~2000Hz, acceleration 196m/s² | |
| Electrical Properties | Electrical properties are the same as the J599 III series electrical connectors | |
| Envirnmental Performance | Temperature Range | -55℃-+85℃ |
| Salt Spray | K Class: 500h F Class: 48h W Class: 500h MW Class: 192h (acidic atmosphere) | |
| Optical Properties | Insertion Loss: | ≤1.0dB |
Main features of the J599 III series hybrid optical fiber and electrical connectors
1. The device is in accordance with GJB599B (MIL-DTL-38999) III series interface standards:
2. The metal part of the shell can be fabricated from different materials and painted to satisfy the different conditions of the atmosphere
3. Five-key positioning, with features for blind insertion and error-proof signaling;
4. Anti-loosening device with three-head-thread quick coupling:
5. Accurate alignment is performed with the help of ceramic pins and sleeves.
6. There are various options of the tail attachments available;
7. Besides, it can also transmit electrical signals along with the optical ones
8. It is an electromagnetic shielding feature.
About Us
TFC was created in 2015 and has its main office in Changsha, Hunan. With more than 6,000 square meters of a standardized workshop, the company takes "Making every connection more reliable, making every piece of data more accurate" as its core value and is committed to supplying customers with performance component products and solutions. It operates with three business divisions: Instrumentation, Connectors, and Sensors. It is a national high-tech enterprise of the future, which integrates R&D, production, testing, and sales and is involved with technologies such as signal connection technology, signal conditioning technology, signal switching technology, and signal detection technology.
R&d team
The company is still committed to the concept of "innovative leadership, continuous improvement, and striving for perfection" by making technological R&D its major core driving force. To provide strong backing to the R&D of core products and quality upgrading, it has formed a high-tech team covering the whole unit of product development, design, process, and testing."
FAQ
Q1: How can I get the relevant technical documents of the product for my selection?
A1: Just get in touch with the sales customer service and ask for complete technical documents, detailed product parameter lists, interface size diagrams, electromagnetic shielding test reports, environmental tolerance verification data, installation and maintenance instructions, etc. as your selection guidance.
Q2: During the use, if the optical/electrical signal transmission is abnormal, what troubleshooting support can the technical department offer?
A2: Technical support will guide you through the troubleshooting process: If the light signal is abnormal, they can help check the cleanliness of the ceramic pins and whether the number of insertions and removals has exceeded the upper limit of 500 times. For abnormal electrical signals, reference can be made to the parameters of the J599 III series electrical connector for circuit verification. Simultaneously, it can help in determining whether environmental factors (like temperature and salt spray) are causing product performance to deteriorate.
