Main parameters of J599A8 series MTP optical fiber connectors
Product Parameters
| Mechanical Properties | Mechanical Life | 500 mating cycles |
| Shock | Peak acceleration 2940m/s², duration 3ms, rate of change of velocity 5.61m/s | |
| Vibration | 10Hz~2000Hz, acceleration 0.4G²/Hz, RMS acceleration 23.1G | |
| Tensile Strength | ≥68N (2mm contact jumper) | |
| Environmental Performance | Temperature Range | -55℃-+125℃ (based on optical cable temperature) |
| Salt Spray | Class K: 500h, Class F: 48h, Class W: 500h, Class MW: 192h (acidic atmosphere) | |
| Air Tightness (Suitable for airtight connecting sockets) | Gas leakage rate ≤1x10⁻⁹Pa.m³/s, internal and external pressure difference is 1 atmosphere | |
| Optical Performance | Insertion Loss | ≤0.6dB |
| Return Loss | ≥ 20dB@850nm |
The main features of the J599A8 series optical fiber cable connectors
1. The size of the interface matches the GJB599B(MIL-DTL-38999)I series, and the functioning is in line with the ARINC801 standard.
2. The device is a multi-channel optical communication carrier, which can be used in avionics, electronics, and ship systems.
3. High alignment accuracy is guaranteed by the use of standard 1.25mm ceramic pins.
4. A ceramic sleeve packaged array that can be disassembled and replaced as a whole, thus facilitating usage and maintenance.
5. The contact piece installation and removal tool M81969/14-03 is simple to work with.
R&d team
The company identifies technological R&D as the main factor which energizes the company and is loyal to the idea perception of "innovation-led, continuous improvement, and pursuit of excellence". To be a source of strength for technology R&D and quality upgrading, it has constructed a high-tech team that covers the entire process of product development, design, process, and testing.
Quality system
Such a company acquired a National Standard (GB) Quality Management System Certification alongside a Weapon Equipment (GJB) Quality System Certification. Moreover, it developed an independent and complete internal quality inspection system. Every product is subjected to stringent full-process tests carried out under the requirements of the national standards (GB) and weapon equipment standards (GJB) so as to guarantee the products' conformity and stability of performance.
FAQ
Q1: Is it possible to acquire a full set of technical documentation for the product?
A1: Definitely, a full technical manual with detailed parameter explanations, installation standards, maintenance instructions, and standard compatibility guidelines that will meet the project acceptance or equipment integration requirements can be provided to you upon your request to customer service or sales.
Q2: What are primary assurances for the mechanical functionality of the product?
A2: The mechanical lifetime is able to be 500 times of insertion and extraction. Tensile strength ≥68N (compatible with 2mm contact piece jumpers); Impulse acceleration can reach 2940m/s² (lasted for 3ms, with velocity change rate of 5.61m/s) without break.
