J599I series electrical connectors
Product Parameters
| Mechanical Properties | Mechanical Life | 500 mating cycles |
| Shock | 3ms half-sine wave acceleration peak 300G | |
| Vibration | Sine vibration frequency 10Hz~2000Hz acceleration 294m/s² Random vibration frequency 100Hz~1000Hz power spectral density 1G²/Hz | |
| Environmental Performance | Temperature Range | Class B -65℃~+175℃ Class E、F -65℃~+200℃ |
| Salt Spray | Class K: 500h Class F: 48h Class W: 500h Class MW: 192h (acidic atmosphere) | |
| Electrical Performance | Insulation Resistance | Normal conditions ≥5000MΩ Humid conditions ≥100MΩ |
| Electromagnetic Interference Shielding | 100MHz~1GHz, minimum attenuation is 85dB 1GHz~10GHz, minimum attenuation is 50dB | |
| Shell-to-shell continuity | Class B ≤2.5mΩ Class E ≤50mΩ Class F ≤1.0mΩ | |
| Other Performance | Relative Humidity | 98% at 40℃ |
| Operating Altitude | ≤30480m |
Features of the J599I series multi-core circular electrical connector
1. It meets the standard of GJB599B (MIL-DTL-38999M) I series;
2. The main features of the bayonet-type quick connection are small size, light weight, and mating contact;
3. In addition to high density, some other advantages;
4. Five keys circular identification and positioning allow blind insertion and mis-insertion prevention;
5. The shell of the connector may be made of different materials and different coatings to meet various environmental requirements:
6. Sockets come in different forms such as a box-type, wall-type, front-mounted, rear-mounted, and nut-fastened mounting;
7. The crimped contacts can be removed, anti-skew design;
8. 9 shell sizes, a variety of contact arrangements:
9. High-strength vibration performance is one of the characteristics;
10. It features electromagnetic shielding.
About Us
TFC came into existence in 2015 and is based in Changsha, Hunan. It has a modernized workshop spread over an area of more than 6,000 square meters and considers "Making every connection more reliable, making every piece of data more accurate" as its main motto, thus, it is committed to supplying customers with performance component products and the whole solution. The firm is split into three divisions; Instrumentation, Connectors, and Sensors. TFC is a national high-tech enterprise of a kind that integrates R&D, production, testing, and sales and is involved in the four core technologies of signal connection technology, signal conditioning technology, signal switching technology, and signal detection technology.
FAQ
Q1: What installation forms are available?
A1: The main different installation types are box type, wall type, front-mounted, rear-mounted and nut-fastened. Besides, the model selection must reflect the equipment installation space, wiring method and fixation requirements in order to choose the proper installation form.
Q2: What should I do if I am not able to make a choice when selecting a model?
A2: The technical support team will be the one to give you selection guidance, single contact pieces, based on the number of your installation space, temperature environment, vibration parameters and electrical requirements, and additionally, they will provide the recommendation of shell numbers, hole arrangements and product categories.
