CMW high-current rectangular connector Structure
The structure of the CMW high-current rectangular connector is also composed of contact pins, modules and frames. It should be noted that for the combination of high current, a 12mm terminal fixing clamp must be selected as an accessory for fixation. The combination form of the CMW high-current automatic mating connector is basically the same, supporting a maximum rated current of 1000A.
Main parameters and product features of CMW high-current rectangular connectors
Product Parameters
| Mechanical Properties | Terminal Insertion/Withdrawal Force | ≤30N |
| Mechanical Life | >100,000 times | |
| Electrical Properties | Working Current | Max.630A |
| Contact Resistance | Max. 45μΩ | |
| Environmental Properties | Neutral Salt Spray | 96H |
1. The CMW automatic plug-in connector can operate at a maximum current of 1000A.
2. The high-current
Rectangular connector parts are very easy to put together and take apart. The connection is efficient
and fast plugging and unplugging are possible.
3. The insertion and extraction life of the high-current rectangular connector is more than 100,000 times.
4. The company merging R&D, design, manufacturing, testing, and sales departments is very cost-effective and
has a high current-carrying capacity. Besides, it can serve as a new energy connector in the new energy industry.
5. We are able to provide our customers with the number of channels they require, thus enabling them to
flexibly expand and configure. Each freely configurable connector can be configured with a maximum of 3 channels.
High-current rectangular connector Application
The company's core products include high-density test connectors, sensors, signal conditioning systems, switching systems, and cable harnesses.
These products have been widely used in high-end industrial fields such as Unmanned aerial vehicles, automotive electronics, aerospace, providing customers with reliable connection and testing solutions.
About Us
Tengfang Zhongke was established in 2015, and its main office is situated in Changsha, Hunan. It possesses a properly-equipped workshop of more than 6000 square meters and, taking "Making every connection more reliable, making every piece of data more accurate" as its motto, is fully committed to providing customers with high-performance component products and solutions. The company has the divisions of Instrumentation, Connectors, and Sensors as its three pillars of business. Being a national high-tech enterprise, the company has integrated R&D, production, testing, and sales functions, and has capabilities in signal connection, signal conditioning, signal switching, and signal detection technologies.
FAQ
Question: Is a high-current rectangular connector one that can handle a current of 1000A or two?
Answer: A high-current rectangular connector refers to one that can carry a current of 1000A.
Question: What is the price of a set of these rectangular connectors approximately?
Answer: The price will be summed up after the configuration is completed, based on the demand. Our company
is a combination of R&D, design, and production activities with fewer intermediates. That is why the price has an advantage.
